TOA A-3512D │MIXER AMPLIFIER 120W
- เครื่องผสมสัญญาณและขยายสัญญาณขนาด 120 วัตต์ รุ่น A-3512D
- Amplifier Class D
- 2 Channel Speaker Zone Selector
- รองรับระบบ Emergency and Priority Paging
- INPUT
- INPUT 1, 2: -60 dB* (MIC)/-20 dB* (LINE) removable terminal block (3.81 mm, 5 pins)/ Ø6.3 mm phone jack (3P)
- INPUT 3: -60 dB*, 600 Ω, electronically-balanced, Ø6.3 mm phone jack (3P)
- INPUT 4: -60 dB* (MIC)/-20 dB* (LINE) selectable, 600 Ω, electronically-balanced, Ø6.3 mm phone jack (3P)
- INPUT 5: -20 dB*, 10 kΩ, unbalanced, RCA pin jack x 2
- PWR AMP IN: 0 dB*, 600Ω, unbalanced, RCA pin jack
- OUTPUT
- Speaker out: Low impedance (8 to 16 Ω)/High impedance (DIRECT, ZONE 1/ZONE 2׃ 100 V/total 170 Ω)
- (ZONE 1/ZONE 2 is selectable, Max. 60 W per output), Removable terminal block (5.00 mm, 6 pins)
- REC OUT: 0 dB *, 600 Ω, unbalanced, RCA pin jack
- LINE OUT 1, 2: 0 dB *, 600 Ω, unbalanced, RCA pin jack (Interlock with zone selection is possible)
- Frequency Response 50 – 20,000Hz (±3dB)
- Indicator Power LED, Signal LED, Peak LED
- Dimensions 420 (W) x 96.1 (H) x 313.1 (D) mm
- รหัสสินค้า A-3512D ยี่ห้อ TOA
฿23,400.00
